Features:
- 5000w heater
- 18 minute heat up time
- DMX operation
- Analogue link sockets
- Approx. 5000m3 smoke output (176,573 cubic
feet/min)
- Fluid level sensing
- Output level control
- 2 x 9.5 liter fluid containers
- Continuous smoke output
- Direct Thermal Protection Device
ON-BOARD LED DISPLAY
This 3 digit LED user interface allows you full and user-friendly
access to the different functionalities of the unit.
On-Board DMX
With onboard DMX you will have access to the machine from
any DMX controller or desk.
DIRECT THERMAL PROTECTION DEVICE (DTPD)
This small yet crucial component is the last line of defence
against catastrophic failure. Pea Soup's DTPD is made from a solid
ceramic composite. This guarantees extremely precise overheat
monitoring and is unaffected by ambient temperature changes.
Electronic Pump Ramping (EPR)
EPR is an intelligent means
of warning of a drop in temperature which could result in
'wet smoke' (residue). The pumps respond to this
signal by running slower and pumping less fluid, thus allowing
the heaters to restore optimum operational temperature. This
guarantees a continuous flow of smoke using highly efficient,
lower wattage heaters.
Electronic Low Fluid Cut-off System
This technology is fitted to all machines designed for continuous
operation. To eliminate the risk of running dry and burning
out the pump, this unique electronic sensing system will automatically
shut-off the machine, protecting all major components.
Soft Start Electronics
The 'crack' created during the initial burst of smoke is caused
by the pump pressure overcoming the incredible back pressure
of the heat exchanger. Pea Soup's unique Soft Start Electronics
gradually powers the pump, eliminating this crack and ensuring
a quieter and smoother operational level following initial
start up.
D-Tec Vaporizing System
This unique system produces a very high smoke output using
a relatively low wattage heat source. The secret is its high
alluvial mass and its twin, cuprous, oval helicoils. 3.5 metre
helicoils and precision casting ensure maximum heat exchange
between the efficient 1500-watt heater and the twin fluid
carrying coils.
On-Board Remote System
Greatly appreciated by rental companies, this hand-held remote
can be stored during transit on-board the machine, making
it easy to find at show time and eliminating transit vulnerability.
But storage isn't the only advantage. Portability is greatly
enhanced by having on board controls.
Analogue Link
Whether you've run out of DMX channels or simply want to link
two smoke/haze machines together and operate them from a single
remote, Pea Soup’s link facility is the solution. This
feature even allows multi-machine connection, making operation
a simple one-finger action.
Fluid Container (2 x 9.5 litre)
All Pea Soup smoke, haze and heavy fog machines are designed
to carry removable fluid containers of varying sizes depending
on the model's application. The removable container makes
for quicker refills and protects the machine from damage through
spillage in transit.
Heat Exchangers (5000W)
All Pea Soup heat exchangers are designed for high efficiency
performance. Only the purest grade LM24 aluminium is used in
the production process which eliminates the risk of porosity
(pockets of gas within the casting which can cause heater
failure). All heat exchangers contain cuprous helicoils of
at least 2.8 metres in length, ensuring a continuous flow
of pure, dry, white smoke.
Editor's note:
Whilst this unit does produce a large volume
of water-based smoke, it is not the most persistent smoke
- for that, see the Phantom
Turbo system which is most suitable for fire training
and large volume smoke logging/coverage. |
